Balance Load Example

About this task

Decision Weight Source Qty Destination Qty Formula Load
SRC1 to DST1 15 20 4 (15 – 20) + 15 + 4 14
SRC1 to DST2 15 20 9 (15 – 20) + 15 + 9 19
SRC2 to DST1 5 9 4 (15 – 9) + 5 + 4 15
SRC2 to DST2 10 9 9 (15 – 9) + 10 + 9 25

Max Source region cost of all available source regions is 15.

User Specified Threshold is 16.

Procedure

  1. Decision SRC1 to DST1, Load is 14, Decision is not eliminated because it does not exceed Threshold.
  2. Decision SRC1 to DST2, Load is 19, Decision is eliminated because it does exceed Threshold.
  3. Decision SRC2 to DST1, Load is 15, Decision is not eliminated because it does not exceed Threshold.
  4. Decision SRC1 to DST1, Load is 14, Decision is eliminated because it does exceed Threshold
